- Movement: The manual sliding stage HF-A40 offers precise, smooth, and stable movement with a minimum scale of 0.01mm, ensuring high- positioning for various industrial applications.
- Durable Aluminum Body: Constructed from lightweight and strong aluminum alloy, this sliding stage is to friction, scratches, drops, and , ensuring long-lasting performance.
- Versatile Applications: Ideal for optical instruments, measuring devices, semiconductor equipment, and more, this sliding stage provides a platform for precise positioning and adjustment.
- Gear Rotation Handle: Easy to operate with a gear rotation handle that controls the dovetail groove guide, allowing for effortless and accurate adjustments.
- Compact Design: With a table size of approximately 40x40mm, this sliding stage is compact and suitable for a wide range of industrial and scientific setups.
Item Type: Manual Sliding Stage
Model: HF-A40
Table Size: Approx. 40 x 40mm / 1.6 x 1.6in
Moving Direction: 1 direction of X Axes
Body Material: Aluminum alloy (black anodized)
Moving Distance Adjustment: This wheel rotates the handle
Sliding Track: Gear guide
Rail Type: Dovetail groove type
Number Of Countertop Threaded Holes: 10Pcs
Threaded Hole Diameter: Approx. 4mm / 0.16in
Threaded Hole Depth: Approx. 6mm / 0.2in
Withstand Load: 29.4N (3Kgf)
Stroke: ±10mm
Minimum Scale: 0.01mm
Parallelism: 30μm
Movement Parallelism: 10μm
Straightness: 3μm
Application: Optical equipment, measuring instruments, semiconductor manufacturing equipment, testing machines, microscopes, handling machines, processing machines, printing machines and others.
Package List：
1 x Sliding Stage
- Package Dimensions : 3.94 x 3.94 x 2.36 inches; 8.54 ounces
- Date First Available : April 24, 2025
- Manufacturer : Enlybee
- Country of Origin : China
